Product Features
>Adopts four- quadrant control technology, enabling bidirectional energy flow within full power range, featuring stable and >reliable operation as well as energy- saving and high efficiency.
>Offers battery simulation and DC programmable operating modes.
>Built- in 5 fixed battery models including LiFePO4, NCM, and LMO, and supports 5 user- customizable battery characteristic curves.
>Equipped with constant resistance, constant voltage, constant current and constant power multiple operating modes.
>Transient response time ≤1ms;
>Utilizes high- speed digital control technology with high output accuracy；
>Employs PWM rectification technology, with a power factor >0.99, input harmonics <3%, and efficiency >95%；
>7-inch touch screen for easy operation, clear visualization and user-friendly HMI.
>Equipped with multiple communication interfaces to support remote operation, unattended operation and integration into test systems.
>Equipped with automatic line voltage compensation function to automatically compensate for line loss.
>Internal components adopt top-tier domestic and international brands for high equipment reliability.
>Adopts modular design and drawer-type mounting for easy disassembly and assembly, which greatly shortens on-site troubleshooting time and improves equipment operation efficiency.；
>Integrated heat dissipation channel design ensures low temperature rise, stable operation and long service lifespan.
