Product Features
>1 MHz high-speed voltage and current sampling rate, 1 μs control resolution；
>50 kHz high-speed dynamic mode with adjustable current rise and fall edges；
>1 kHz transmission rate for voltage, current and other parameter communication；
>Adopts 1 MHz high-speed, high-precision sampling and control technology；
>Adjustable CV loop speed to match various power supplies；
>Short-term loading capacity up to twice the rated power；
>More than 20 test functions: sequence test, auto test, short-circuit simulation, timing measurement, discharge test, internal resistance test, overcurrent test, overpower test, frequency sweep test, load effect test, LED simulation, sine wave function, etc.
>Multiple operation modes: CC, CV, CR, CP, CV+CC, CR+CC, CV+CR, CP+CC；
>Supports 50 sequence files, up to 100 steps per file, with file linking function；
>Standard interfaces: LAN, RS232, RS485; optional GPIB, USB, CAN. Equipped with isolated high-speed external digital and analog monitoring interfaces；
>Comprehensive protection functions: overvoltage, overcurrent, overpower, overtemperature, current oscillation protection, current limit, power limit, reverse polarity alarm, etc.
